https://www.criticallink.com/	FPGA, MCU boards	Intel, TI
https://www.compulab.com/	CPU boards, SBC	NXP, TI
https://www.mixtile.com/	SOMs	Rockchip
https://www.atronik.ru/	SOMs, SBC, CPU modules	Атроник
https://www.data-modul.com/		Data Modul
https://www.congatec.com/		Congatec
https://www.tq-group.com/		TQ-Embedded
https://www.kontron.com/		Kontron
https://edge.seco.com/		Seco
https://www.adlinktech.com/		Adlink
https://www.avnet.com		Avnet
https://www.advantech.com/		Advantech

Форм-факторы процессроных модулей

QSeven

SMARC

Com Express

COM Express

https://www.portwell.com/pdf/embedded/PCOM-B634VG.pdf

Portwell

SOM модули

↓ link	pn	formfactor	manufacturer	cpu	emmc	ram	temprange	dp	hdmi	lvds	ethernet	dsi	csi	usb2	usb3	pcie	can	spi	i2c	smbus	uart	dimension	bios	datasheet_wiki	page_wiki

adlink_nanox-el	nanoX-EL	COM Express Type 10	Adlink	Intel Atom x6000E	16/32/64 GB	2/4/8/16 GB LPDDR4	0...+60 °C, -40...+85 °C	1 DP/HDMI/VDI		Single Channel via eDP<>LVDS IC (or eDP)	1 (2.5 GBit, SGMII) (GPY211/GPY215)	-	-	6(8)	2	x4 x 1, x2 x 2, x1 x 4 gen 3	1 (in place of UART1)	+ (BIOS, TPM)	1 (from EC, option from CPU)	1	2 (UART1 or CAN) (from EC, from CPU option)	84 x 55 mm	AMI UEFI	link	page
adlinktech_lec-el	LEC-EL	SMARC	Adlinktech	Intel® Atom® x6000E Celeron® Pentium® Elkhart Lake	16\32\64 GB	2\4\8 GB LPDDR4x	0...+60\-40...+85 °C	2 (or 1 hdmi)	1 (or dp)	1 2ch(or dsi\edp) (NXP PTN3460)	2 (2.5 GBit) (GPY211)	1 (or edp\lvds 2ch)		6	2	4 gen 3 (1x4, 2x2, 4x1)	2	1 + 1 espi			4 (2 full)	82x50	AMI Aptio V	link	page
advantech-som-2532	SOM-2532	SMARC	Advantech	Intel® Atom® x6000E Celeron® Pentium® Elkhart Lake	64 GB	16 GB LPDDR4x	-40...+85 °C	2 (or 1 hdmi)	1 (or dp)	1 2ch(or dsi\edp)	2 (Marvell 88E1512)	1 (or edp\lvds 2ch)		6	2	4 gen 3 (1x4, 2x2, 4x1)	2	1 + 1 espi			4 (2 full)	82x50	AMI Aptio V	link	page
advantech_som-7532	SOM-7532	COM Express Type 10	Advantech	Intel Atom x6000E	32/64 GB	2/4/8/16 GB LPDDR4	0...+60 °C, -40...+85 °C	1 DP/HDMI/VDI		Single Channel via eDP<>LVDS IC (or eDP)	1 (2.5 GBit, SGMII) (I225)	-	-	6(8)	2	x4 x 1, x2 x 2, x1 x 4 gen 3	-?	+ (BIOS, TPM 2.0)	1 (from EC\CPU)	1 (from EC\CPU)	2 from EC/2 CAN friom EC/2 CAN from SoC	84 x 55 mm	AMI UEFI 256Mbit	link	page
congatec_conga-ma7	Conga-MA7	COM Express Type 10	Congatec	Intel Atom x6000E	32/64 GB	2/4/8/16 GB LPDDR4	0...+60 °C, -40...+85 °C	1 DP/HDMI/VDI		Single Channel via eDP<>LVDS IC (or eDP)	1 (1 GBit, SGMII) (TI DP83867CS)	-	-	6(8)	2	x4 x 1, x2 x 2, x1 x 4 gen 3	-?	+ (BIOS, TPM 2.0)	1 (from EC\CPU)	1 (from EC\CPU)	2 from EC/2 CAN friom EC/2 CAN from SoC	84 x 55 mm	AMI UEFI 256Mbit	link	page
congatec_conga-sa5	conga-SA5	SMARC	Congatec	Intel Atom E3900	32 GB	8 GB LPDDR4x	-40...+85 °C	2 (or 1 hdmi)	1 (or dp)	1 2ch(or dsi\edp)	2 (i210, i211)	1 (or edp\lvds 2ch)	2 (x4, x2)	6	2	up to 4 gen2	2	2	2		4 (2 full)	82x50	AMI Aptio® V UEFI 2.x firmware, 8 MB serial SPI	link	page
congatec_conga-sa7	conga-SA7	SMARC	Congatec	Intel Atom x6000E	128 GB	16 GB LPDDR4x	-40...+85 °C	2 (or 1 hdmi)	1 (or dp)	1 2ch(or dsi\edp)	up to 4	1 (or edp\lvds 2ch)		6	2	up to 4 gen3	2	2	2		4 (2 full)	82x50	AMI Aptio 32 MB serial SPI	link	page
data_modul_edm-smx-el	eDM-SMX-EL	SMARC	Data Modul	Intel® Atom® x6000E Celeron® Pentium® Elkhart Lake	64 GB	16 GB LPDDR4x	-40...+85 °C	2 (or 1 hdmi)	1 (or dp)	1 2ch(or dsi\edp)	2	1 (or edp\lvds 2ch)		6	2	4 gen 3 (1x4, 2x2, 4x1)	2	1 + 1 espi			4 (2 full)	82x50	AMI Aptio V	link	page
kontron_come-mel10	COMe-mEL10	COM Express Type 10	Kontron	Intel Atom x6000E	16/32 GB	2/4/8 GB LPDDR4	0...+60 °C, -40...+85 °C	1 DP/HDMI/VDI		Single Channel via eDP<>LVDS IC (or eDP)	1 (2.5 GBit, SGMII) (GPY115/GPY215)	-	-	6(8) (port7 client)	2	x4 x 1, x2 x 2, x1 x 4 gen 3	2 (in place of UART0/1)	+ (BIOS, TPM)	1 (from EC)	1	2 (UART or CAN) (from EC, from CPU option)	84 x 55 mm	AMI Aptio V uEFI	link	page
kontron_smarc-sxel_e2	SMARC-sXEL E2	SMARC	Kontron	Intel® Atom® x6000E Celeron® Pentium® Elkhart Lake	64 GB	16 GB LPDDR4x	-40...+85 °C	2 (or 1 hdmi)	1 (or dp)	1 2ch(or dsi\edp)	2	1 (or edp\lvds 2ch)		6	2	4 gen 3 (1x4, 2x2, 4x1)	2	1 + 1 espi			4 (2 full)	82x50	AMI Aptio V	link	page
portwell_pcom-b634vg	PCOM-B634VG	COM Express Type 6 Basic	Portwell	Intel Pentium/Xeon D-1500	-	up to 48 GB DDR4 (3 x SODIMM)	-40...+80 °C			1 (SM750)	1 (1 GBit) (I210-IT)			8	3	x16 gen 3 x 1, x1 gen 2 x 8					2			link	page
portwell_pcom-ba02gl	PCOM-BA02GL	COM Express Type 10	Portwell	Intel Atom x6000E	16/32 GB	4/8/16 GB LPDDR4	0...+60 °C, -40...+85 °C	1 DP/HDMI/VDI		Single Channel via eDP<>LVDS IC (or eDP)	1 (1GBit? 2.5 GBit?, SGMII? PCIe?) (GPY215? I210AT?)	-	-	6(8)	2	x4 x 1, x2 x 2, x1 x 4 gen 3	-?	+ (BIOS, TPM 2.0)	1 (from EC\CPU)	1 (from EC\CPU)	2 from EC	84 x 55 mm	AMI BIOS	link	page
seco_som-smarc-ehl	SOM-SMARC-EHL	SMARC	SECO	Intel® Atom® x6000E Celeron® Pentium® Elkhart Lake	64 GB	16 GB LPDDR4x	-40...+85 °C	2 (or 1 hdmi)	1 (or dp)	1 2ch(or dsi\edp)	2	1 (or edp\lvds 2ch)		6	2	4 gen 3 (1x4, 2x2, 4x1)	2	1 + 1 espi			4 (2 full)	82x50	AMI Aptio V	link	page
tq-embedded_tqmxe39s	TQMxE39S	SMARC	TQ-Embedded	Intel Atom® x5/x7 E3900 series (“Apollo Lake-I“) Pentium® N4200 and Celeron® N3350 processors	64 GB	8 GB LPDDR4	-40...+85 °C	2 (or 1 hdmi)	1 (or dp)	1 2ch(or dsi\edp)	1 (i210)		2	4 (1 OTG)	2	4 gen 2 (1x4, 2x2, 4x1)		1	1	1	4	82x50		link	page
tq-embedded_tqmxe40m	TQMxE40m	COM Express Type 10	TQ-Embedded	Intel Atom® x6000 series Elkhart Lake	8...256 GB	4/8/16 GB LPDDR4/4x	0...+60 °C, -40...+85 °C	1 (or hdmi)	1 (or dp)	1 1ch (or edp)	1 1G (Marvell 88E1512)	-	-	6(8)	2	4 gen 3 (1x4, 2x2, 4x1)	1 (or SER1)	1	1/2 optional	1	2/1 + 1 CAN (2 full optional)	82x50	InsydeH2O 64bit uEFI	link	page
tq-embedded_tqmxe40s	TQMxE40S	SMARC	TQ-Embedded	Intel Atom® x6000 series Elkhart Lake	256 GB	16 GB LPDDR4x	-40...+85 °C	2 (or 1 hdmi)	1 (or dp)	1 2ch(or dsi\edp)	2	1 (or edp\lvds 2ch)		4	2	4 gen 3 (1x4, 2x2, 4x1)	2	1 + 1 espi	1	1	4 (2 full)	82x50		link	page
tq-embedded_tqmxe41s	TQMxE41S	SMARC	TQ-Embedded	Intel® Atom® x7000E Celeron® Pentium® Alder Lake-N	256 GB	16 GB LPDDR5	-40...+85 °C	2 (or 1 hdmi)	1 (or dp)	1 2ch(or dsi\edp)	2 (2.5Gb Intel i226)	1 (or edp\lvds 2ch)		6	2	4 gen 3 (1x4, 2x2, 4x1)	2	1 + 1 espi			4 (2 full)	82x50		link	page
